The Strait Type Reduce DC Motor
Price: 0 $
- Parameters
- Downloads
-
The Product Name:The Strait Type Reduce DC Motor
The Product Model:FT-DC-50
The working Voltage:3V
The current no load:150mA
The speed no load:50RPM±10%
The stall torque:3kgf.cm
The stall current:750mA
Product details
| Model: | FT-DC-50 | |||
| Product Name: | he Strait Type Reduce DC Motor | |||
| Storage Temperature RangeRange:e: | -30℃～80℃ | |||
| Operating Temperature | -15℃～70℃ | |||
| Operating Voltage Range: |
3V |
|||
| Runnig current(at no load) : |
150mA |
|||
| No load speed: | 50RPM±10% | |||
| Peak stall torque: | 3kgf.cm | |||
| Stall current: |
750mA |
|||
| Model: | FT-DC-90 | |||
| Product Name: |
The Strait Type Reduce DC Motor |
|||
| Storage Temperature RangeRange:e: | -30℃～80℃ | |||
| Operating Temperature | -15℃～70℃ | |||
| Operating Voltage Range: | 3V | |||
| Runnig current(at no load) : |
70mA |
|||
| No load speed: | 90RPM±10% | |||
| Peak stall torque: |
1.2kgf.cm |
|||
| Stall current: |
500mA |
|||
| Model: | FT-DC-60 | |||
| Product Name: | The Strait Type Reduce DC Motor | |||
| Storage Temperature RangeRange:e: | -30℃～80℃ | |||
| Operating Temperature | -15℃～70℃ | |||
| Operating Voltage Range: | 3V | |||
| Runnig current(at no load) : | 60mA | |||
| No load speed: | 55RPM±10% | |||
| Peak stall torque: | 1kgf.cm | |||
| Stall current: | 250mA | |||
| The Drawings: | ||||
